Description
Dry type oil-free compressors (working pressure: 1.5 ~ 10 bar) are used in special processing fields, such as electric power, metallurgy, electronics, aviation, chemical, papermaking, Pharmaceutical, food, bottle blowing and cap making.
Dry type oil-free air blowers (working pressure: 0.4 ~ 1.5 bar) are used in sewage treatment, oxidation desulfurization, pneumatic conveying and other fields. In the field of aeration, the pressure can be automatically adjusted according to the change of water depth, and due to the wide range of working pressure adjustment, strong dust resistance, high efficiency and stability performance. It has become the most economical blower for the transformation of roots blowers.
SUCCESS ENGINE oil-free screw compressor and air blower adopts dry type single-stage or double-stage compression, and the main airend is rotated by the coupling, in the compression chamber, there is no other liquid involved, so the compressed air is clean and oil-free.
|
Model |
Power kW |
Pressure Bar |
Air Flow m3/min |
Outlet Connection |
Weight KG |
Dimension L*W*H mm |
|
ZA75(W)-1.5 |
75 |
1.5 |
20 |
DN65 |
2100 |
2900*2300*1880 |
|
ZA75(W)-2(2.5) |
2(2.5) |
19(17) |
||||
|
ZA75(W)-3 |
3 |
16 |
||||
|
ZA100(W)-1.5 |
100 |
1.5 |
32 |
DN80 |
2300 |
2900*2300*1880 |
|
ZA100(W)-2(2.5) |
2(2.5) |
29(26) |
||||
|
ZA100(W)-3 |
3 |
21 |
||||
|
ZA120(W)-1.5 |
120 |
1.5 |
34 |
DN80 |
2600 |
2100*2300*2050 |
|
ZA120(W)-2(2.5) |
2(2.5) |
33(29) |
||||
|
ZA120(W)-3 |
3 |
26 |
||||
|
ZA150(W)-1.5 |
150 |
1.5 |
38 |
DN100 |
3000 |
3100*2300*2050 |
